FRAME Prime 6061 Xtralite Fully Butted Alloy, Forward Geometry, internal removable battery, tapered head tube, Boost 12x148mm rear axle, integrated dropout speed sensor
FORK RockShox Recon Silver RL 29, 100mm, Motion control, Solo Air, tapered steerer tube, Boost 15x110mm axle, 32mm steel stanchions, 42mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload
STEM MDK Urban 40mm 5º, 6061 forged alloy, 31.8mm barbore
GRIPS Onoff Shaper
SADDLE MDK urban
REAR BRAKE Sram Level T, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad
RIMS MDK-HP1 29, 30mm internal width, tubeless ready, 32 spokes
FRONT HUB Formula DC711, Boost 15x110mm, sealed bearings, IS 6 bolts
FRONT TIRE Maxxis Grifter 29x2.5, single compound, 60TPI, wire bead, tanned wall.
CRANKSET Race Face Aeffect ebike, 165mm
CHAIN Sram SX Eagle, 12s, Powerlock
SHIFT LEVERS Sram Trigger SX Eagle, 12s, X-Actuation 1:1, single click
DERAILLEUR HANGER Mondraker M068
WEIGHT 24,3 kg
MOTOR Bosch Performance Line CX Cruise (25Km/h) GEN4
SIZES XS: 380mm / S: 390mm / M: 430mm / L: 470mm / XL: 510mm
HEADSET Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
HANDLEBAR MDK Urban 1.0 double butted 6061 alloy, rise: 20mm, width: 680mm, 9º backsweep, 5º upsweep, 31.8mm barbore
SEATPOST Onoff Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 31.6mm, length 400mm
FRONT BRAKE Sram Level T, 2 piece caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pad
BRAKE LEVER Sram Level T, Direct Link actuation, tooled reach adjust, lever pivot bushings
SPOKES CN round stainless steel
REAR HUB Formula EHL148 Boost 12x148mm, sealed bearings, IS 6 bolts
REAR TIRE Maxxis Grifter 29x2.5, single compound, 60TPI, wire bead, tanned wall.
RINGS Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD
REAR DERRAILLEUR Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1
CASETTE Sram PG-1210, 11-50T, 12s
OTHERS Front light: 50LUX output DC 6-12V, waterproof Alloy cage. Rear Light: Fender Mount, w/ Reflective, e-bike version, 6-12V. Fenders: Alloy black MDK custom fenders. Rack: Alloy MDK rear Rack, Max loading 25kg. Kickstand: Massload KSA18-40
DISPLAY Bosch Kiox 300 / Bosch Led Remote
BATTERY Bosch Powertube 625Wh
